Custom GTL2T Gaston marine low-clearance electric hoist

Anhui Gaston Precision Machinery Co, Ltd. Home / Product / Pneumatic Hoist Series / GTL Series Low Headroom Electric Hoist / GTL2T Gaston marine low-clearance electric hoist
  • GTL2T Gaston marine low-clearance electric hoist

GTL2T Gaston marine low-clearance electric hoist

GTL2T Gaston marine low-clearance electric hoist is specially designed for the marine industry. It has won the trust of shipowners and marine engineers around the world with its performance and reliability. This pneumatic hoist not only has the characteristics of high efficiency and safety but also fully considers the particularity of the ship's working environment, providing strong support for ship operations. The GTL2T Gaston marine low-clearance electric hoist also incorporates intelligent technology. By integrating sensors and control systems, it enables automated operation and remote monitoring. Operators can remotely control and monitor the hoist through smart devices, and understand the operating status and performance data of the equipment in real-time. This not only improves operating efficiency but also reduces operational risks and ensures the safety and reliability of ship operations. The GTL2T Gaston marine low-clearance electric hoist is widely used in many fields such as ship cargo handling, equipment hoisting, and maintenance operations, providing strong support for the daily operation and maintenance of ships.

  • DETAIL PARAMETERS

Performance characteristics of air hoist

Air pressure

(PSI)

Air pressure

(Mpa)

 Maximum Power (HP) Free speed (rpm) Speed ​​at maximum power (rpm) Torque at maximum power (NM) Air consumption at maximum power (m3/min) Stop torque and start torque (NM)
40 0.28 45% 80% 30% 37.50% 45% 45%
50 0.35 56% 84% 44% 52.40% 56% 56%
60 0.4 67% 88% 58% 65.90% 67% 67%
70 0.48 78% 92% 72% 78.30% 78% 78%
80 0.55 89% 96% 86% 89.60% 89% 89%
90 0.63 100% 100% 100% 100% 100% 100%
100 0.7 110% 104% 114% 109.60% 110% 110%

The figure shows a typical pneumatic motor torque and power curve at two different air pressures. The motor speed, torque and power decrease as the air pressure decreases. The figure shows the torque and speed curves of the pneumatic motor under two different air pressures. The speed and torque of the motor decrease as the air pressure decreases. The torque decreases significantly, while the motor speed decreases slightly as the pressure decreases.

Performance curve graph

Technical Data Sheet

Pneumatic hoist Model M o l d Unit HQ2-2 HQ3-1 HQ3-2 HQ6-2 HQ10-2
Air pressure            Mpa 0.4 0.6 0.4 0.6 0.4 0.6 0.4 0.6 0.4 0.6
Load Tons 2 3 3 6 10
Number of chains root 2 1 2 2 2
Motor output power KW 1.5 2 1.8 3.5 1.5 2 1.8 3.5 1.8 3.5
Lifting height M The standard height is 3 meters
Full load lifting high speed m/min 2.5 2.7 2.5 5 2 2.5 1.2 2.5 0.8 1.5
Full load descent speed m/min 5 5.5 7.5   11 8 11   3.5 5.5 2.5 3.5
Full load gas consumption - increased m3 / min 0.7 1.2 2 4 1.8 2.6 2 4 2 4
Chain size mm 9*27 13*36 9*27 13*36 16*45
Chain weight KG/M 1.8 3.8 1.8 3.8 5.8
Standard weight (3m lifting height) KG 38 86 68 115
Controller air pipe length m Standard length is 3 meters
Full load noise - increased db 74 78 74 78 74 78 74 78 74 78
Trachea connector in G3/4 G3/4 G3/4 G3/4 G3/4
Air pipe size (inner diameter)  mm 14 19 19 19 19
Walking car Motor power KW 0.25 0.25 0.25 2 2
Full load speed m/min 13 13 13 10 10
Motor air consumption m³/min 0.45 0.25 0.25 2 2
Trachea connector  in G1/2 G3/4 G1/2 G3/4 G3/4
Air pipe size (inner diameter) mm 13 13 13 19 19
Weight (trolley)  KG 40 75 49 75 89

Dimensions

Dimensions

Pneumatic hoist HQ3-2 HQ6-2 HQ10-2
Walking car QDC-3 QDC-6 QDC-10
A 725 930 930
B 400 530 530
b Running track width range 110-150 200-250 200-250
bm 235 330 350
C 530 695 695
D 120 135 166
E 34 68 68
F 220 291 291
G 284.5 302 306
H 417 650 650
J 446 605 605
L 234 293 303
M 203.5 249 256
N 35 48 66
