LXMLXM Gaston High Viscosity Screw is a specialized component designed for use in machinery that handles high-viscosity materials. This screw is engineered to efficiently mix and convey viscous substances, ensuring consistent processing and reducing the risk of material degradation. Its robust construction is made to withstand the high pressures and shear forces associated with high-viscosity applications. The screw's design may include features like a deep flight design for better material hold-up and a hardened surface for increased durability. It's typically used in industries such as plastics, chemicals, food processing, and pharmaceuticals where high-viscosity materials are a common challenge.
DETAIL PARAMETERS
Performance parameters | |
Max. flow rate | 38L/m |
Max. pressure | 40m(pneumatic), 60m(electric) |
Max. temperature | 90℃ |
Max. viscosity | 15000cps |
Max. share | 1.5 |
Length of pump pipe | 1000mm |
Driving mode | Pneumatic or electric motor |
Motor
Model | Name | Power | Speed |
AM1.3 | Air motor | 1100W | 300-3000rpm |
AMV3 | Air motor | 3000W | 300-3000rpm |
AM3.9 | Air motor | 3900W | 300-2500rpm |
AMP5 | Air motor | 1100W | 300-3000rpm |
GM752 | Ordinary motor | 750W | 3000rpm |
